The coupling KTR BoWex SD1 curved-tooth gear

Mã sản phẩm : BOWEX SD1

Xuất xứ : KTR-GERMANY

Bảo hành : According to manufacturer standards

• The double-cardanic curved-tooth gear coupling BoWex SD1 is a coupling type shiftable at standstill to quickly connect and disconnect driving and driven side. • Slip ring and shiftable linkage for manual operation of this gear coupling are part of the scope of delivery. These couplings are frequently used, as an example, in belt drums.

Giá sản phẩm : 0985.288.164

HOTLINE TƯ VẤN : 0985.288.164

Detail

• The polyamide material allows permanent maintenance-free operation with a very good coefficient of tooth friction.
• According to the dual action principle of BoWex gear coupling, the restoring force can be neglected with angular and radial displacements and no periodic oscillations of angular velocity appear.
• BoWex gear couplings can be assembled in a vertical or horizontal design.
• Smooth and hard surface (crystalline structure) with high thermal stability and resistance to lubricants, fuels, hydraulic fluids, solvents, etc. making polyamide an ideal material for components subjected to sliding loads, especially for the manufacture of couplings..
